AIR KING UNIVERSAL COUPLINGS ("CP" COUPLINGS)

CP Hose End

Air King is for air service only!

Do not use CP Fittings with Steam

Malleable IronBrass316 S/S
Hose EndsSizePart #Part #Part #
3/8"AMHABHRAMH
1/2"AM1AB1RAM1
5/8"AM5AB5-
3/4"AM6AB6RAM6
1"AM11AB11RAM11
Male NPT Ends1/4"AMB1ABB1-
3/8"AMBABBRAMB
1/2"AM2AB2RAM2
3/4"AM7AB7RAM7
1"AM12AB12RAM12
Female NPT Ends1/4"AMC1ABC1-
3/8"AMCABCRAMC
1/2"AM3AB3RAM3
3/4"AM8AB8RAM8
1"AM13AB13RAM13
Blank EndsAM0AB0RAM0
Triple ConnectionsAM10AB10-

Air King Safety Pins
Wire DiameterPart #
.058"AKSP1
.091"AKSP25
Air King Washers
DescriptionPart #
RubberAWR4
NeopreneAWS6
Safety ClipsS/S Safety ClipsLanyards
AC1AC7ACL8

Note: The use of an Air King Safety Clip or wire type retainer is necessary to assure Air King Universal Couplings will not become accidently disconnected. This guarantees the fittings are properly connected as the pin will not go through holes in mating flanges until couplings are locked in place. Only one Air King Safety Clip or wire type retainer is required for each Air King Universal Coupling.
Note: Air King is rated to 110 PSI. Standard Air King fittings come with AWR4 washers.
Note: Air King available to meet Mil Spec. WWC-633D on special order.

Air King Hose Ends with Ferrules

Air King with Ferrule
SizeHose OD RangeMalleable Iron316 S/S
From:To:Part #Part #
1/2"27/32"1-1/32"AM1WFRAM1WF
3/4"1-1/16"1-11/32"AM6WFRAM6WF
1"1-18/64"1-34/64"AM11WF-1-
1"1-30/64"1-46/64"AM11WFRAM11WF

Note: Malleable Iron and Stainless Steel Air King Couplings with Carbon Steel Ferrules can be crimped or swaged on. Please call our Customer Service Department for crimp or swage diameter recommendations. Rated to 110 PSI Working Pressure.

3/4" Male Air King with Gauge Port
Part #Material
AM7TMalleable Iron
RAM7TStainless Steel
Note: Drilled to 1/4" NPT for mounting gauge. Gauge is not included.

Air King Universal Swivels
SizePart #
1/2" Male NPTAM2SWIV
3/4" Hose EndAM6SWIV
3/4" Male NPTAM7SWIV
3/4" Female NPTAM8SWIV
Note: These Malleable Iron Universal Swivel fittings interchange with other Air King fittings and include a heavy-duty, free-turning joint that will swivel under pressure to prevent hose kinking. Working Pressure is 110 PSI.
For Air Service Only!

King 4-Lug Quick-Acting Couplings

Four Lug CP
4-Lug FittingsSizeMalleable IronBrass
Part #Part #
Hose Ends1-1/4"AM16AB16
1-1/2"AM21AB21
2"AM26AB26
Female NPT Ends1-1/4"AM18AB18
1-1/2"AM23AB23
2"AM28AB28
Washers: (Fits all 4-Lug Fittings) Part # AWR14
Warning: For water service only. Not to be used for steam service!
Note: Safety Clips are the same size for both 2-lug and 4-lug couplings.
Use Safety Clips on all Universal Coupling applications.
